IN1

2

I

Forward rotation logic input.

IN2

3

I

Backward rotation logic input.

OUT1

8

O

Forward rotation output.

OUT2

5

O

Backward rotation output.

VDD

4

Power

Positive power.

GND

6

Power

Negative power.

N.C.*

1.7

-

No connection.

IN1

IN2

OUT1

OUT2

Function

0

0

Z(Off)

Z(Off)

Stop (Standby)

1

0

1

0

Forward

0

1

0

1

Backward

1

1

0

0

Brake

VDD - VSS

Supply voltage

-0.5 ~ +7.5

V

IOUT-PEAK

Output peak current

2.5

A

θJA

Thermal resistance (Junction to Ambient)

SOP-8

150

°C/W

P_D

Power dissipation

SOP-8

0.9

W

T_A

Operating ambient temperature

-40 ~ +85

°C

T_J

Operating junction temperature

+160

°C

TST

Storage temperature

-55 ~ +150

°C

VDD

Operating voltage

1.8

6.8

V

ISB

Standby current

0.1

1

uA

IN1=IN2=0

IOP

Operating current

V_DD = 3.0V

120

uA

IN1=1, IN2=0 or

IN1=0, IN2=1 or

IN1=1, IN2=1

V_DD = 6.0V

210

uA

IIH

Input high current (12kΩ pull-low resistance)

250

uA

V_IH = 3.0V

500

uA

V_IH = 6.0V

VIH

Input high voltage

2.0

V

VIL

Input low voltage

0.8

V

RON

Output resistance

(SOP-8 Package)

0.40

Ω

I_OUT = 200mA

0.42

Ω

I_OUT = 500mA

0.45

Ω

I_OUT = 800mA

IOUT

Output continuous current  (* with PCB heat dissipation)

1400

1600*

mA

SOP-8

IPULSE

Pulsed drain current

5.0

A

Pulse width < 20ms

TRISE

Output rise time

300

ns

PWM=20kHz, Duty=50%

TFALL

Output fall time

150

ns

TRP

Input-to-Output response time

300

ns

TTSD

Thermal shutdown (TSD)

160

°C

Junction temperature

TTSDH

Thermal shutdown hysteresis

45

°C
